KX5600 Ultrasound

KX5600 Portable Ultrasound Scanner

Product information

Ultrasound

Reviews

4 out of 5 stars

Description

Rechargeable Human Ultrasound Scanner -KX5600

Color

Additional details

  • Humanized design
  • Rapidly one-key operation includes one-key storage, one-key browse and one-key print
  • Unique CPU temperature control function, when the temperature is too high, it can automatically shut down.
  • Rotatable LED Panel to make the users get the best image visual sense from different angles.
  • One-key to light the keyboard, suitable for operation dark room
  • Practical function knob design,use A key to realize quick adjustment in a variety of conditions.
  • Main basic configuration:
  • Main unit 1pc
  • 3.5MHz convex probe 1pc
  • Power supply adaptor 1pc
  • Reticle 1pc
  • Two probe sockets

Additional More details

  • 10.4’ high resolution color LED backlight display, with high contrast and wide viewing angle
  • Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable
  • Menu operation system, with different languages according to requirement including Spanish, English, French, Russian and Portuguese
  • Two probe sockets, auto-identify different optional probe
  • Body marks:total 64 kinds body marks indicating probe position
  • Optional parts:
  • Optional probes
  • 6.5MHz multi-frequency trans-vaginal probe(through vagina)
  • 6.5MHz micro-convex probe for small animals
  • 7.5MHz multi-frequency linear probe
  • 7.5MHz multi-frequency cavity probe (through anus)
  • Battery charger
  • Li-battery: HYLB-1614 11.1V-4400mAh 48.84Wh
  • trolley
  • Video printer(UP-897MD)
  • Ethernet Switch

Additional More details

  • Display mode:B,2B,4B ,B/M,M
  • Adjustable depth: 10 grades, max depth to 236mm
  • Gain:0-127dB
  • Contrast:27-90dB
  • Gray scale:256
  • 8 steps intelligent TGC
  • Frame frequency: 30 frames /second
  • 8 kinds pseudo colors
  • Image storage: 4G hard disk to permanently store about 5000 frames images without loss when power off
  • Cine loop:256 frames
  • Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position)
  • the gravel software package with real-time position line measurement
  • Normal measurement: distance,perimeter, area, volume, angle, length and area stenosis ratio measurement.
  • Cardio measurement:Depth, slope, heart rate, cycle
  • Gynecology measurement and analysis: gynecology general measurement and gynecology report
  • OB measurement including: 15 kind of obstetric software, several GA measurement, amniotic fluid index ,fetal growth curve and OB report
  • Urology measurement and analysis: residual urine volume, prostate volume, and urology report
  • One-key store: concise and practical
  • One-key review:fast, practical image review function
  • One-key Print
  • One-key Transfer the current frozen image to net workstation to complete its image text report and print directly
  • Concise and practical, easy operation. The system includes network workstation to complete data & report management (You don’t need to invest more to buy extra ultrasound working station)
  • Unique One-key-light keyboard function for black room use
  • Display brightness adjustable
  • Dual TV output: PAL/NTSC, can connect video printer when necessary
  • Power supply:100-240V, 1.2-0.6A frequency:50-60Hz
  • Power supply adaptor output:DC12.8V 3.0A
  • Main unit weight:4.5kg(without accessories)
  • Main unit dimension:256 x 150 x 326mm(L x W x H)
  • Dimension: 320mm x 300mm x 120mm - Weight:3.5Kg
